LPW4 (Build - 02)

LPW4 (Build - 02)

Engine

LPW4
Engine Code LPW4 (build - 02)
Engine Description 4 CYLINDER WATER COOLED DIRECT INJECTION DIESEL ENGINE
Build Description 3000r/min Variable Speed.Fuel Stop Power
Standard Equipment FLYWHEEL AND RING GEAR  |  FLYWHEEL HSG WITH SAE5 FLANGE  |  FUEL AGGLOMERATOR  |  FUEL LIFT PUMP  |  HEATER PLUG  |  INLET & EXHAUST MANIFOLDS  |  LIFTING EYE  |  LUBRICATING OIL FILTER  |  OPERATORS HANDBOOK  |  PAINT  |  SELF VENT FUEL SYSTEM  |  TAPPING FOR SPEED DETECTION  |  WATER PUMP AND THERMOSTAT  |
Engine Speed
1500 1800 2000 2500 3000
Engine Power
r/min 1500 1800 2000 2500 3000
kw 15 18.7 21.2 26 29.5
bhp 20.11 25.08 28.43 34.87 39.56
Cooling Water
Fuel Diesel
Fuel Consumption
  1500 1800 2000 2500 3000
litre/hr 3.8 4.6 5 6.3 7.8
gal/hr 1.00 1.21 1.32 1.66 2.06
height
(mm / inches)
574 / 22.39
width
(mm / inches)
470 / 18.33
length
(mm / inches)
696 / 27.14
Torque
r/min 1500 1800 2000 2500 3000
Nm 95.5 99.2 101.2 99.3 93.9
lbf ft 70.48 73.21 74.69 73.28 69.30
Emissions No
Service Interval 500 hours
Governing Mechanical
Oil Capacity 5.3 L
Rotation Anti-clockwise
Start Method Electric
No of
Cylinders
4
cylinder capacity
(litre / in3)
1.86 / 113.50
Bore Size
(mm / in)
86 / 3.35
Stroke
(mm / in)
80 / 3.12
Compression 18.5
Country of
manufacture
ENGLAND
Accessories AIR CLEANERS  |  ELECTRICAL CONTROL EQUIPMENT  |  EXHAUST EQUIPMENT  |  FAN DRIVE GUARDS  |  FLWHEEL END DRIVES AND ADAPTORS  |  HYDRAULIC PTO  |  PROTECTION SWITCHES AND F.C. SOLENOID  |  RADIATORS AND FANS  |


Additional Info
